Advance CPP Propeller HI Series
ADVANCE CPP (Controllable Pitch Propeller) technology originated in France and the Netherlands. With its exceptional performance and wide-ranging applications, it has established a strong industry influence globally. To date, this technology has been successfully implemented in over 3,000 vessels worldwide, spanning various shipping sectors from commercial cargo ships to specialized vessels. Known for its outstanding adaptability and efficiency, ADVANCE CPP technology precisely meets the increasingly diverse demands of modern shipping.
To ensure optimal compatibility with different types of vessels, ADVANCE has meticulously developed three unique series of adjustable propellers: the HI series, renowned for its superior heavy-load performance and reliability, excels in applications for heavy-duty vessels; the HF series achieves a perfect balance between efficiency and versatility, making it suitable for a variety of conventional marine scenarios; and the HS series, specifically designed for high-speed vessels, meets the stringent requirements for power and control during high-speed navigation with its high precision and flexibility. These product series fully demonstrate ADVANCE's innovative capabilities in marine propulsion technology and its deep understanding of customer needs.
Five-Blade Propeller for High-Speed Ships
CPP Hub
Advanced CPP Series Propellers
Advantages Of Controllable Picth Propellers
Optimized blade section geometry in cooperation with Marine: effectively reduces cavitation and increases propulsion efficiency.
Tailor-made hydrodynamic analysis makes the ship have good utility performance.
The excellent computer team will perform finite element analysis on each set of adjustable paddles to ensure the strength and reliability of the equipment.
The OD box is installed at the front end of the gearbox for easy installation, detection and maintenance.
Has a unique security design, hydraulic failure, pitch can be locked in place when reversing and ahead position.
Combined with the advantages of gear box and highly flexible coupling, comprehensive consideration of the matching between subsystems to ensure the perfection of the whole system.
Realize the integration of CPP and gearbox hydraulic system to reduce installation costs.
HI Series Propellers Hub
The HI series propeller hub is specifically designed for vessels with power ranges from 250 kW to 5000 kW.
Embracing the philosophy of "simplicity without compromise, reliability above all," it stands as the ideal choice for heavy-duty operating conditions.
Renowned for its exceptional durability and stability, the HI series hub is widely used in complex operational environments such as high-speed vessels, scientific research ships, multi-purpose offshore engineering vessels, specialized fishing boats, and ice-class navigation ships.
Whether tackling high-intensity maritime tasks or navigating under extreme climatic conditions, the HI series propeller hub delivers robust power support and reliable operational performance, fully meeting the demands of various vessels in the most challenging working conditions.
| Model | Shell Diameter | Dimensions | |||||
|---|---|---|---|---|---|---|---|
| a | b | c | d | e | Vmin | ||
| HI-035 | 350 | 250 | 145 | 70 | 332 | 65 | 250 |
| HI-040 | 400 | 275 | 165 | 80 | 370 | 65 | 270 |
| HI-045 | 450 | 300 | 180 | 90 | 400 | 65 | 285 |
| HI-050 | 500 | 330 | 210 | 105 | 450 | 65 | 300 |
| HI-055 | 550 | 360 | 230 | 110 | 490 | 65 | 330 |
| HI-060 | 600 | 390 | 250 | 120 | 550 | 65 | 350 |
| HI-065 | 650 | 420 | 270 | 130 | 590 | 65 | 375 |
| HI-070 | 700 | 445 | 295 | 140 | 620 | 98 | 390 |
| HI-075 | 750 | 495 | 315 | 150 | 680 | 98 | 400 |
| HI-080 | 800 | 525 | 340 | 160 | 700 | 98 | 410 |
| HI-085 | 850 | 560 | 355 | 165 | 750 | 98 | 415 |
| HI-090 | 900 | 590 | 380 | 170 | 805 | 98 | 420 |
